20′ x 12′ x 11′ Tote Storage Building

20′ x 12′ x 11′ Tote Storage Building

TS 2012 TOTE STORAGE

20′ x 12′  •  17′ ROLL-UP DOOR  •  4 WIDE  •  16 UNIT CAPACITY

Four Hour Fire-Rated Chemical Tote and Barrel Storage Building with Roll-Up Door Open.

The image above is intended as a generic example of our tote storage products, and not a literal representation of specific dimensions and/or product features.

20′ x 12′ x 11′ Tote Chemical Storage Building

With pre-approved accessories, these 100% compliant and customizable buildings multiply hazardous material storage capacity.

Forklift access is an option on both sides of the building, with large swing or roll-up style doors. The static grounding system, seismic bolt-down plates, and 2-part epoxy coating (inside and out), guarantee protection from environmental factors and temperature extremes throughout the term of our 20-year structural warranty on all hazmat IBC Tote Chemical storage units.

Dimensions:

Interior – 18’⅞” x 10’⅞” *

Exterior – 19’1⅜” x 11’1½” x 11’4″ *

Storage Capacity (Totes)16

* Accessories may increase dimensions.

TS 2012 Tote Dimensions & Storage Capacity CAD

12 Ft. Wide Chemical Building Storage Capacities:

4012 - 40 Ft. 12' Wide Storage Capacity Flyer

Most chemical tote storage buildings come equipped with:

  • EPA-compliant secondary spill containment sump with optional 1” grated steel flooring
  • Natural air ventilation
  • Continuous-weld 12-gauge construction for lasting durability
  • UL-listed doors, load center, electrical accessories and components
  • Integrated structural floor system exceeds 1,000 lbs per square foot
  • Durable corrosion, weather, and chemical-resistant interior and exterior coatings
  • Additional options and accessories available

Also Available:

Fire-Rated Flammable Chemical Storage Buildings

Flammable and combustible chemical storage with two-hour or four-hour fire rating and explosive proof compliance.

Learn more…
